Luvocom® 3F PAHT CF 9742 BK Filament

LUVOCOM® 3F PAHT CF 9742 BK is a premium carbon fiber-reinforced 3D printing filament, engineered for industrial applications demanding high performance and reliability. This PA6-based material is enhanced with 15% carbon fiber, offering superior mechanical properties and ease of use. This particular engineering polymer grade is tailored made for the 3D printing industry to match the injection molding strength requirements and focusing on the serial production of end-parts, the filament can be used on conventional FFF / FDM 3D printing systems without an heated chamber. This 3D4Makers PAHT CF filament features the following properties:

• Easy to Print: Excellent printability with minimal warping and improved layer adhesion for high-quality results.
• High Z-Strength: Exceptional strength in all directions, making it ideal for functional and structural parts.
• High-Temperature Resistance: Withstands demanding environments, ensuring durability under heat.
• ESD Safe: Suitable for sensitive electronic applications, providing electrostatic discharge protection.

Material properties

Description	Value	Test method
Density	1,25 g/cm³	ISO 1183-3
Tensile  strength (at 23°C/50% rh)	170 MPa	ISO 527
Elongation @Fmax	1 %	ISO 527
Tensile modulus (dry, @1 mm/min)	15 GPa	ISO 527
Impact strength (dry)	47 kJ/m²	ISO 179 1eU
Heat distortion temp.	200 °C	ISO 75
Continuous service temperature (20.000 h)	150 °C	EC 60216
Service temperature (during lifetime max. 200h)	180  °C	/
Insulation resistance strip electrode (R25)	≤10² Ω	DIN IEC 60167
Surface resistance (ROB)	<10² Ω	DIN IEC 60093

Printer recommendations

Description	Value
Printer nozzle temperature	260 - 290°C
Heated bed temperature	60 - 80°C
Print Speed	40 - 60 mm/s
Bed Adhesion	Magigoo PA on glass or a PEI Sheet
Pre drying recommendations	- 100°C, 4 - 6 hours or 80°C, 12 hours - Profile also available for Drywise In-Line Dryer
Extra	We advise to use a adapted nozzle (>0.5mm) for carbon filled filaments

*Printing profile available in Ultimaker Marketplace

To get the best results while printing we advise you to keep the 3D printer in a room where there is hardly any draft and/or temperature fluctuations. When the 3D printer is not being used it is important to keep filament in a bag and stored in a cool, dry and dark place until it is used again.
