PETG Filament

PETG (Polyethylene Terepthalate Glycol-modified) Filament

Technical information:

PETG Filament (Polyethylene Terepthalate Glycol-modified) is the common thermoplastics of the polyester family and is used in fibers for clothing, bottles for liquids and foods. This material is easy to print and has a glossy and smooth surface finish, due to great thermal characteristics the print will cool efficiently resulting in minimal warpage and strong layer bonding. The mechanical properties features high impact resistance and excellent flexibility.

Measurements & Tolerance

Size	Diameter tolerance	Roundness
1,75 mm Filament	+/- 0,05mm	95%
2,85 mm Filament	+/- 0,10mm	95%

Material properties

Description	Value	Test method
Density	1,27 g/cc	ISO 1183
Tensile strength at yield	50 MPa	ISO 527
Tensile modulus	2020 MPa	ISO 527
Flexural modulus	2050 MPa	ISO 178
Impact strength - Charpy method 23ºC	8,1 kJ/m²	ISO 179
Transparency	90%	ASTM D1003
Heat deflection temp.	70˚C	ASTM D648

Printer settings

Description	Value
Printer nozzle temperature	220 - 240°C
Heated bed temperature	60 - 80°C
Bed Adhesion	Magigoo Original on glass or a PEI Sheet

Additional info

To get the best results while printing we advise you to keep the 3D printer in a room where there is hardly any draft and/or temperature fluctuations.

When the 3D printer is not being used it is important to keep the 3D4MAKERS PETG Filament in a bag and stored in a cool (15-25˚C) and dry room away from UV light until it is used again.
